AS307A Anti-Microbial Medical Barcode Scanner (Bluetooth + Memory + USB)

Arkscan AS307A (second generation of MT1197MW), the Anti-Microbial mini barcode scanner with Bluetooth Wireless, USB 2.0 wired and built-in memory for Data Collecting.

AS307A is the most compact Bluetooth barcode scanner designed for particular medical uses with no hassle, The friendly firmware algorithm of non-pin code pairing technology allows users to easily pair with devices, AS307A is less size 60%~80% compared with handheld scanners, can easily connect to a mobile tablet with iOS, Android, and/or Windows-base OS by one click.

Many medical applications already use barcode scanners as quick input peripherals when fulfilling prescriptions. By developing Surgical Nursing Preparation Carts, nowadays, these peripheral devices can be replaced by a durable smartphone or a mobile table together with AS307A anti-microbial barcode scanner, it is ready for Medical Application

The built-in vibrator makes AS307A medical barcode scanner possible to perfectly operate in quiet environment and/or noisy workplace. Equipped with a silicone cover, AS307A can be fully protected and immune to water drops and dust, too.

AS307A mini pocket scanner is the smallest wireless memory barcode scanner in its class. It is tiny at L65 x W24 x H18 mm and only 24.6 g in weight, which is ideal to be carried in pocket or purse.

It's designed for healthcare / medical industry with antimicrobial protection, vibrating indicator and industrial silicone cover, the AS307A medication barcode scanning With silicone cover that comes with the product, the scanner is fully protected and immune to rain drops and dust.

It's ideal for batch operation, AS307A as a data collector with 2MB memory of storing up to 20,000 barcodes

One year warranty includes part and labor; life time unlimited technical support, please contact us if you run into any technical issue or concern. Arkscan barcode scanners have a rich set of features which we might not able to cover all of topics in our hundreds pages user manual, we are more than happy to help you to solve problems and get what you need. Please visit Arkscan website to get help.



User Friendly
Stand-alone portable scanner easily transfer scanned data to computer device via Bluetooth or USB interface; Wireless interface supports all Bluetooth modes, SPP & HID, such as Apple IOS(iPad & iPhone), Android, Tablet and Mac.

Excelent Optical Performance
High sensitivity image engine that delivered fast and accurate scanning performance in 240 scan per second for medical uses. Supports all major 1D barcodes reading from near contact to as far as 144mm away; 5000 reads per charge, and unlimited reads with a charging cable connected.

Can Store up to 20,000 Barcodes
2MB memory for data storage designed for batch operation, AS307A medical barcode data collector is capable of storing up to 20,000 barcodes and ensures the data is retained even when battery loses power.

Versatile Functionality
Scan barcode on paper, as well as scan barcode off LCD & LED screen, such as barcode on screen of iPhone, iPad, Android, Blackberry, Windows phone & most smartphone device.

Non-Disruptive Indicators
Built-in vibrator makes AS307A the medical barcode scanner possible to perfectly operate in quiet environment and/or noisy workplace
Optical & Performance
Light Source
525 nm visible green LED

Sensor Linear Imager sensor
Scan Rate
240 Scans/Sec
Resolution
5mil/ 0.127mm
Scan Angle
46°
Print Contrast
30%
Width of Field
102mm (13Mil Code 39)
D.O.F
(Environment:800lux)
5 Mil Code39: 20 ~ 70mm
10 Mil Code39: 30 ~ 130mm
15 Mil Code39: 45 ~ 180mm
13 Mil UPC/ EAN: 40~130mm
Physical Characteristics
Dimension W27×L68×H15 mm
Weight 27g
Color White
Material PC
Trigger Scan Button,
iOS Hotkey
Indicator buzzer, LED, Vibrator
Power
Operation Voltage 3.7 VDC ± 5%
Working Current < 220mA
Standby Current < 65mA
Idle Current < 500uA
Battery 3.7V, 400mAh, Lithium Battery
Number of Scan (per full charge) 5400 scans (1 scan/ 5 secs, Bluetooth connected)
Connectivity
Radio Bluetooth 2.1 + EDR (Class2)
Range 33 ft/ 10m (line of sight)
Interface/ Profile SPP (Android, Mac, Windows)
HID (Android, iOS, Windows)
User Environment
Operating Temperature -0~50˚C
Storage Temperature -20~60˚C
Humidity 0%~95%RH (Non-condensing)
Drop Durability 1.8M (w/ Silicone Cover)
Sealing IP44 (w/ Silicone Cover)
Ambient Light 20,000 Lux (Fluorescent Light)
1D Symbologies UPC-A/UPC-E, EAN-8/EAN-13, Industrial 2 of 5, Codabar, Matrix 2 of 5, Code 11, Code 93, Code 32, Code 128, Standard Code 39, Full ASCII Code 39, Interleaved 2 of 5, China Postal Code, MSI Plessy Code, UK Plessy Code, EAN/UCC 128, Telepen Code, IATA Code, GS1 Databar
Regulatory
EMC CE, FCC part15, Class B
ESD Functional after 4KV contact, 8KV Air discharge
Safety RoHS 2.0, WEEE
Description Notes Date Download
AS307A Quick Guide User Manual   Dec 28, 2014 Download Now

Additional download for AS307A:
Description Notes Date Download
Wireless Quick Connection Setup Card One page quick guide for bluetooth pairing, the Quick Guide user manual also has the same content as this.  Nov 20, 2015 download
Complete User Manual Full version of the barcode scanner's user manual. It may includes other barcode scanner model's setting content which it might not applied this particular model. Dec 28, 2014 Download Now
Wireless Barcode Scanner Connection Guide More detail on how to pair other devices. Dec 28, 2014 Download Now
Utility Tool 5.04 Utility tool to config barcode scanner. It's NOT recommended for new barcode scanner user. You don't need this tool to operate the barcode scanner. Sept
6, 2017
Download Now
SM3 VCP Driver The driver is for VCP (Virtual COM Protocol), if you don't know what it is, please do NOT install it. 99% of users use the barcode scanner via HID interface, HID works like a keyboard, a scanned barcode's value is input to where the cursor is, and you don't need driver to use the HID interface. Oct
8, 2013
Download Now
Factory Reset Barcodes This pdf document contains the necessary barcodes in order to perform a full factory reset. This would be most helpful for troubleshooting your barcode scanner. Sep 9, 2018 Download Now
Intercharacter Delay Barcodes In some cases, your host device may not pick up all of the characters that were scanned using your barcode scanner. The most common cause for this is because the barcode scanner is sending data faster than the speed in which the host device can read it. To remedy this issue, download the "Intercharacter Delay Barcodes" sheet and our recommended speed is "16mS" to ensure that all of the data properly transfers into to your host device. Click Here for a video guide on how to set your Intercharacter Delay. Nov 14, 2018 Download Now

Play Video - Pairing Your Bluetooth Barcode Scanner with your Android device
This video guide will walk you through how to get started using your wireless Bluetooth barcode scanner. We go over pairing your Bluetooth scanner to your Anroid device!

Play Video - Pairing Your Bluetooth Barcode Scanner with your iOS Device
This video guide will walk you through how to get started using your wireless Bluetooth scanner. We go over pairing the device as well as finding solutions to common issues such as the iOS device not receiving the barcode data properly and being able to easily switch between on screen display typing and scanning.
